HERO XTREME 160R PROGRAMMED FI - FEATURES - STEERING LOCK OPERATION; HANDLEBAR SWITCHES CONTROL - LEFT HANDLEBAR CONTROLS

20
HANDLEBAR SWITCHES CONTROL
1. Headlamp dimmer switch
The headlamp operates only when the engine
is running or when passing switch is operated.
Press the switch (1) upwards for high beam
“ ” downwards for low beam “ ”.
Left handlebar controls
FEATURES
Steering lock
Steering lock is with the ignition switch, turn
the key (1) to “OFF” ( ) position & turn the
handle bar towards left or right & push the key
downwards & turn towards "Lock" position.
After locking take out the key.
(1) Ignition key
1
Shift the turn signal switch (2) sideways for
right/left indications and leave it to come
back to its normal position on its own.
2. Turn signal lamp switch ( )
(2) Turn signal switch (3) Horn switch
(4) Hazard switch
(1) Headlamp dimmer switch
3. Horn switch ( )
To turn “OFF” the indicator lamps in hazard
switch “ON” condition, press the hazard
switch again.
4. Hazard switch ( )
Press the switch to operate the horn (3).
Press the hazard switch (4) in ignition "ON"
condition whenever your vehicle becomes a
temporary hazard for other road users and it is
necessary to park the vehicle due to
breakdown or other unavoidable problems.
Upon pressing the hazard switch, all turn
signal lamps start flashing simultaneously to
warn other road users behind you of a hazard
or obstruction ahead.
32
IMPORTANT : To switch “OFF” the turn
signal after completing the turn, gently push
the switch inside.
1
4
NOTE
Use hazard lights only when your vehicle becomes
a temporary hazard for other road users.
