62
•
Headlamp adjustment is done by the
loosening the bolt (1) located below the
headlamp.
Headlamp is preset. However in case of
adjustment required, please follow the steps
as given below:
HEADLAMP FOCUS ADJUSTMENT
•
Park the vehicle on it main stand on level
ground.
•
Adjust the headlamp beam by loosening the
bolt (1) and moving the headlamp unit
forward and backward for correct focus
adjustment.
•
Turn the ignition switch to “ON” position
( ) and start the engine.
1
(1) Headlamp adjusting bolt
•
Turn the adjusting nut (2) to position stop
lamp switch at a point where the stop lamp
glows once the brake pedal is depressed.
Turn the adjusting nut in direction (A) to
advance switch timing or in direction (B) to
retard switch timing.
A
B
(1) Stop lamp switch (A) Advance
(2) Adjusting nut (B) Retard
2
WARNING
!!
An improperly adjust headlamp may blind
oncoming rider/driver or it may fail to light
the road for a safe distance.
CATALYTIC CONVERTER
This vehicle is equipped with a catalytic
converter (1) in the muffler to meet the
emission norms.
The catalytic converter contains precious
metals that serve as catalysts, promoting
chemical reactions to convert the exhaust
gasses without affecting the metals. The
catalytic converter acts on HC, CO and NOx.
The catalytic converter must operate at a high
temperature for the chemical reactions to take
place. It can set on fire any combustible
material that come near it. Park your vehicle
away from high grasses, dry leaves, or other
flammable material.
1
•
Tighten the bolt after adjustment.
