24
Fuel tank capacity is 12 litres (Minimum fuel
to be maintained above one segment blinking
of fuel level indicator).
FUEL TANK
(1) Key hole cover (2) Ignition key
(3) Fuel tank cap
3
Ÿ Do not overfill the tank. There should be no
fuel (4) in filler neck (5). Fill the tank with
fuel as shown.
Ÿ To unlock fuel tank cap, lift the key hole
cover (1), insert key (2) turn it clockwise
and lift open the cap (3).
2
1
WARNING
!!
Regularly inspect the functionality of "Side
stand engine kill” feature and in case of any
malfunction visit Authorised Hero MotoCorp
workshop.
(4) Fuel (5) Filler neck
4
5
Ÿ To lock fuel tank cap, close the cap back on
the opening and press gently. The key
springs back to the normal position and cap
gets locked.
Ÿ Remove the key and put back the keyhole
cover.
If your vehicle doesn't operate as described in
above flow diagram, please visit your
Authorised Hero MotoCorp workshop.
