Ÿ Start the engine & let it idle for 3-5
minutes.
Ÿ Do top up if oil level reaches towards the
lower level mark or every 3000 km
whichever is earlier.
Ÿ Park the vehicle on its main stand.
Ÿ Slightly loosen the engine oil check bolt (4)
and check the engine oil entry into the
cylinder head cover.
(4) Engine oil check bolt
37
Ÿ Savita Oil Technologies Limited.
Ÿ Bharat Petroleum Corporation Limited.
Ÿ Tide Water Oil Co. (India) Ltd.
Manufactured by:
(JASO MA ).2
Engine oil level inspection/
Top up process
OIL CAPACITY : 1.3 litres
Check engine oil level each day before
operating the vehicle. The oil level dipstick (1)
is on the right crankcase cover for measuring
oil level. Oil level must be maintained between
the upper (2) and lower (3) level marks on
the oil level dipstick.
ENGINE OIL
BRAND: Hero 4T plus
GRADE: SAE 10W 30 S Grade L
Use hero genuine engine oil or recommended
grade oil.
UPPER
LOWER
(1) Oil level dipstick (2) Upper level mark
(3) Lower level mark
2
Ÿ Quantity of oil to be filled is 1.09 litres
(approx.) during oil change (when right
crankcase cover is not removed).
Ÿ Remove the oil level dipstick, wipe it clean
and insert without screwing it in.
Ÿ Stop the engine and wait for 2-3 minutes.
Ÿ If required, add the specified oil up to the
upper level mark. Do not overfill.
Ÿ After checking the oil circulation, tighten the
engine oil check bolt.
Ÿ Remove the oil level dipstick and check the
oil level.
4
3
1
