(1) Fuel gauge (2) Segments(1) Fuel gauge (2) Segments
(3) One segment
Please ensure the vehicle is not used
continuously when the fuel level indicator
reaches the one segment blinking. It will not only
result in the vehicle running out of fuel, it may
also cause serious damage to the fuel pump.
Please ensure fuel is filled up as soon as the fuel
level indicator reaches one segment blinking.
CAUTION
!!
NOTE
To check the fuel level indication, the vehicle
should be on levelled surface and in stationary
condition.
3
NOTE
NOTE
After getting the vehicle serviced, make sure
that the service reminder indicator has been
reset.
(1) Service reminder indicator
1
122
The digital segments (2) will swing to
maximum scale on the meter console once the
ignition switch is turned “ON” ( ). If all the
segments are displayed it means fuel quantity
in the fuel tank is 12.0 litres.
If only one segment (3) is displayed and
blinks, this indicates the fuel quantity is low
and the fuel tank should be refilled as soon as
possible.
19
( ) Service reminder indicatord
The service reminder indicator can reset at be
an Authorised workshop.Hero MotoCorp
The ervice eminder ndicator ( ) is to s r i 1
indicate the user to bring the vehicle to an
Authorised workshop for Hero MotoCorp
service. The indicator shall start blinking when
the vehicle covers kilometers as specified in
the maintenance schedule. The indicator will
keep on blinking throughout the kilometer
interval for a particular service and will stay
‘‘ON’’ thereafter.
The fuel gauge (1) indicates approximate fuel
available in the form of digital segments.
(e) Fuel gauge
