40
areas, more frequent may be replacement
necessary.
• Remove the air cleaner cover screws (1)
and the cover (2).
• (page 25).Remove the seat assembly
(1) Side cover screws (2) Side cover
•
Remove the air cleaner element (3).
3
(3) Air cleaner element
NOTE
Align the tabs of air cleaner cover before
installing screws & the cover.
1
2
CAUTION
!!
• wet, paper pleated Never wash or clean the
type filter. Replace filter element once in
every 15000 km.
• Replace it earlier if it becomes very dirty,
damage on surface or on the sealing area.
•
Install the seat ).(page 25
•
Install the air cleaner element cover.
•
Clean the air cleaner housing using a shop
towel.
•
Install the new air cleaner element.
Air cleaner drain tube cleaning
Follow the above process more frequently
when riding in rain or at full throttle.
Remove the drain tube (1) and drain the
deposit into a container.
