V-Switch quad II - Installation and Operation Manual
ON SCREEN DISPLAY
19
SECURITY LEVEL 8
Security level 8 allows you to work only on one channel (computer) in a predefined display mode (Quad,
Fullscreen or PiP mode). No settings can be changed, apart from the SECURITY menu item, where you can
change the security level.
SYSTEM SECURITY
SECURITY LEVEL 7
As security level 8, but you can open OSD windows that only show display modes and device settings.
CONSOLE VIDEO OUTPUT/EDID
VIDEO INPUT STATUS
COMPUTER KEYBOARD/MOUSE/EDID/DDC
HELP HOTKEY/ABOUT/CONTACT
SECURITY LEVEL 6
As security level 7, with the following additional operations:
SYSTEM CONTROL
CONSOLE FADE
- Setting of active channel using front panel buttons, Hotkeys or Hotmouse
- Selecting channel with PiP button in Quad mode
- Changing the directly selectable PiP channel in PiP mode single direct
SECURITY LEVEL 5
As security level 6, with the following additional operations:
- Setting of display mode (Quad / Fullscreen / PiP) using front panel buttons, Hotkeys or Hotmouse.
SYSTEM TEST PATTERN
Note:
Before changing the security level, please set the configuration you wish to work with to the higher
security level, under MODE u START (see page 31). This configuration will be maintained when
V-Switch quad II is reset, in case of power failure, or when power is turned off and on again.
OSD - SYSTEM - SECURITY
