VIDEO INPUT (Display Video Formats)
Mode Resolution Sync Refresh rate Set in VESA / CEA
polarity analog digital* EDID Standard
H/V Hz Hz
CGA 640x350 +/- 85 85 DMT
CGA 640x400 -/+ 85 85 DMT
EGA 720x400 +/+ 70 70 x CVT
EGA 720x400 -/+ 85 85 DMT
VGA 640x480 -/- 60 22 - 60 x DMT
VGA 640x480 -/- 72 72 x DMT
VGA 640x480 -/- 75 75 x DMT
VGA 640x480 -/- 85 85 x DMT
SVGA 800x600 +/+ 56 22 - 56 x DMT
SVGA 800x600 +/+ 60 60 x DMT
SVGA 800x600 +/+ 72 72 x DMT
SVGA 800x600 +/+ 75 75 x DMT
SVGA 800x600 +/+ 85 85 - 180 x DMT
XGA 1024x768 -/+ 50 22- 50 CVT
XGA 1024x768 -/- 60 60 x DMT
XGA 1024x768 -/- 70 70 x DMT
XGA 1024x768 +/+ 75 75 x DMT
XGA 1024x768 +/+ 85 85 x DMT
XGA/B 1152x864 +/+ 75 75 x DMT
SUN 1152x900 +/+ 66 66 CVT
HDTVp 1280x720 +/+ 50 22 - 50 CEA-861-E
HDTVp 1280x720 +/+ 60 60 CEA-861-E
WXGA 1280x768 -/+ 60 60 DMT
UWXGA 1280x960 +/+ 60 60 DMT
UWXGA 1280x960 +/+ 85 85 DMT
SXGA 1280x1024 g 50 50 CVT
SXGA 1280x1024 +/+ 60 60 x DMT
SXGA 1280x1024 g 72 72 CVT
SXGA 1280x1024 +/+ 75 75 x DMT
SXGA 1280x1024 +/+ 85 85 x DMT
WXGA 1360x768 +/+ 60 22 - 60 DMT
SXGA+ 1400x1050 -/+ 50 22 - 50 CVT
SXGA+ 1400x1050 -/+ 60 60 DMT
SGI 1600x1024 +/+ 60 60 CVT
UXGA 1600x1200 +/+ 50 50 CVT
UXGA 1600x1200 +/+ 60 60 x DMT
UXGAr 1600x1200 +/+ 50 50 CVT
UXGAr 1600x1200 +/+ 60 60 CVT
WSXGA 1680x1050 -/+ 60 60 DMT
HDTVp 1920x1080 +/+ --- 22 - 24 CEA-861-E
HDTVp 1920x1080 +/+ 50 50 CEA-861-E
HDTVp 1920x1080 +/+ 60 60 x CEA-861-E
WUXGAr 1920x1200 +/+ 50 22 - 50 CVT
WUXGAr 1920x1200 +/+ 60 60 x DMT
SUPPORTED VIDEO INPUT
Note:
* digital: all video formats up to 162 MHz pixel clock following DMT, CVT or GTF standard timings
are supported. Within this range ANY digital resolution is supported.
Analog input may not be detected correctly. See page 47 EDID/DDC.
