HETEC V-Switch quad II User Manual

V-Switch quad II - Installation and Operation Manual
ANNEX
74
VIDEO OUTPUT (Display Video Formats)
The table lists all video formats supported by V-Switch quad II at the output port.
Mode Horizontal Vertical Hz
VGA 640 480 60
VGA 640 480 75
VGA 640 480 85
SVGA 800 600 60
SVGA 800 600 75
SVGA 800 600 85
XGA 1024 768 50
XGA 1024 768 60
XGA 1024 768 70
XGA 1024 768 75
XGA 1024 768 85
SXGA 1280 1024 50
SXGA 1280 1024 60
SXGA 1280 1024 75
SXGA+ 1400 1050 50
SXGA+ 1400 1050 60
UXGA 1600 1200 50
UXGA 1600 1200 60
UXGAr 1600 1200 50
UXGAr 1600 1200 60
XGA/B 1152 864 75
UWXGA 1280 960 60
UWXGA 1280 960 85
SUN 1152 900 66
WXGA 1280 768 60
WXGA 1366 768 60
WSXGA 1680 1050 60
WUXGAr 1920 1200 40
WUXGAr 1920 1200 50
WUXGAr 1920 1200 60
HDTVp 1280 720 50
HDTVp 1920 1080 24
HDTVp 1920 1080 50
HDTVp 1920 1080 60
SUPPORTED VIDEO OUTPUT
Note:
When set to auto (by default) V-Switch quad II reads the EDID of the monitor connected and
automatically supports its resolution.
Note:
Fluid video performance:
With digital input and a resolution of 800x600, the input frame rate may be increased up to 180 Hz.
This provides smooth video output even in Quad mode. To use this feature, it is necessary to choose
this resolution and refresh rate on all devices connected to the V-Switch quad II’s video inputs.
