1 2
3
4
5
6
1. Tachometer unit (Square type)*
2. Tachometer unit (Round type)*
3. Speedometer unit (Square type)*
4. Speed & fuel meter unit (Square type)*
5. Speed & fuel meter unit (Round type)*
6. Fuel management meter (Square type)*
Fuel tank
If your model was equipped with a portable
fuel tank, its function is as follows.
WARNING
The fuel tank supplied with this engine is
its dedicated fuel reservoir and must not
be used as a fuel storage container. Com-
mercial users should conform to relevant
1. Fuel joint
2. Fuel gauge
3. Fuel tank cap
4. Air vent screw
Fuel joint
licensing or approval authority regula-
tions.
This joint is used to connect the fuel line.
To Next Page
