Instruments and indicators
Low oil pressure-alert indicator
If oil pressure drops too low, the alert indica-
tor will start to blink. For further information,
see page 43.
NOTICE
●
Do not continue to run the engine if the
low oil pressure-alert indicator is on and
the engine oil level is lower. Seri- ous
engine damage will occur.
●
The low oil pressure-alert indicator
does not indicate the engine oil level.
1
1. Overheat-alert indicator
Use the oil dipstick to check the re-
maining oil quantity. For further infor-
mation, see page 49.
Digital speedometer
This gauge shows the boat speed and other
information.
1. Low oil pressure-alert indicator
Overheat-alert indicator
1. Speedometer
2. Fuel gauge
3. Trip meter/clock/voltmeter
4. Alert indicator(s)
If the engine temperature rises too high, the
alert indicator will start to blink. For further in-
formation on reading the indicator, see page
43.
NOTICE
Do not continue to run the engine if the
overheat-alert indicator is on. Serious en-
gine damage will occur.
All segments of the display will light momen-
tarily after the main switch is turned on and
will return to normal thereafter.
Speedometer
The speedometer displays km/h, mph, or
knots, according to operator preference. Se-
lect the desired units of measurement by set-
ting the selector switch on the back of the
gauge. See the illustration for settings.
