Hidea F40 User Manual

12
Specifications and requirements
TIP:
Specifications
“(AL)” stated in the specification data below
represents the numerical value for the alumi-
num propeller installed.
Likewise, “(SUS)” represents the value for
stainless steel propeller installed and “(PL)”
for plastic propeller installed.
TIP:
“*” means, select the engine oil referring to
the chart of engine oil paragraph. For further
information, see page 16.
Dimension:
Overall length:
F40 711 mm (28 in)
F60 711 mm (28 in)
Overall width:
F40 409 mm (16 in)
F60 409 mm (16 in)
Overall height L:
F40 1382 mm (54.4 in)
F60 1448 mm (57 in)
Transom height L:
F40 527 mm (20.7 in)
F60 527 mm (20.7 in)
Weight (AL) L:
F40 112.6 kg (248.2 lb)
F60 1118.5 kg (261.2 lb)
Performance:
Full throttle operating range:
F40 5000–6000 r/min F60
5000–6000 r/min
Maximum output:
F40 29.4 kW@5500 r/min
(40 HP@5500 r/min)
F60 44.1 kW@5500 r/min
(60 HP@5500 r/min)
Engine:
Type:
4-stroke L
Displacement:
F40 747 cm
3
F60 996.0 cm
3
Bore  stroke:
65.0  75.0 mm (2.56  2.95 in)
Ignition system:
CDI
Spark plug (NGK):
F40 DPR6EB-9
F60 DPR6EB-9
Spark plug gap:

Hidea F40 Specifications

General

Brand	Hidea
Model	F40
Category	Outboard Motor
Language	English
