6-2 General Maintenance x.Spot ™User Manual
Error Message Troubleshooting
X.Spot fixtures display errors in 8-character form when the menu system is locked.
Unlocked, you can find a more detailed description in the two-line format menu system.
See an explanation of navigating to the Display Errors option on page 3-28. The
following pages list some of the error messages available in x-Spot fixtures. For other
error messages, contact customer service for assistance, see “Contacting High End
Systems®” on page ii.
Always check wiring connections as the first step in identifying problems
indicated by error messages, see “Wire Harness Connections” on page 6-9.
Since driver boards are interchangeable, functionality can be verified by
replacing a board with another board of it’s type on the fixture, see “Replac-
ing a Driver Board” on page 5-6.
3-phase board LD1 Green No Board receiving proper voltage
Dim green Yes Board not receiving data
OFF Yes Board not receiving power
LD2 Red No HD6 sensor open
Green No HD6 sensor closed
Flashing red Yes Board not receiving data
OFF Yes Board not receiving data or power
LD3 Green No Board programmed properly
Flashing red Yes Board not programmed
CPU board LD1 Orange No Receiving information from 2 & 3 phase
boards
LD1 Dimly
flickering
Yes Not receiving information from 2 & 3 phase
boards
LD2 Green No Board receiving proper voltage
OFF Yes Board not receiving power
LD3 Red No Currently not used
LD4 Green No Receiving data
OFF Yes, if data
is applied
Not receiving data
Data Com
board.
Receive Green No Receiving data
OFF Yes, if data
is applied
Not receiving data
Transmit Red No Transmitting data
OFF Yes, if data
is applied
Not transmitting data
Table 6-1 LED State
Location LED # State Problem? Description
