x.Spot™ User Manual Fixture Operation 3-21
3
3. Use the left and right arrows on the Navigation button to scroll to SELECT USER
MODE and press the Enter button to select.
4. Use the up and down arrows on the Navigation button to the A or B User Mode
and press the Enter button to store.
Protocol Mode
This option sets the Protocol to be followed in assigning Start Channels and
programming parameters. STANDARD protocol is the default on x.Spot fixtures. As
other protocols are implemented for x.Spot fixtures, they will be available in this
menu.
Copy Users
Use this menu to copy the parameter defaults, preset values or both from one User
mode to the other.
To COPY USERS:
1. Press the Menu button to unlock the menu system or to move back up the system
to the top level menus.
2. Using the left and right arrows on the Navigation button, scroll to the FIXTURE
MODE MENU and press the Enter button to select.
3. Use the left and right arrows on the Navigation button to scroll to COPY USERS
and press the Enter button to select.
4. Using the left and right arrows on the Navigation button scroll to COPY PRESET to
copy only the preset settings, COPY PARAMETERS to copy the parameter defaults
or COPY ALL and press the Enter button to store.
5. Use the up and down arrows on the Navigation button to select A B or A B
and press the Enter button to store.
Crossloading Fixture Software
A fixture running a newer software version can load the new software to all other
x.Spot fixtures on the link using the CROSSLOAD FIRMWARE menu option.
To CROSSLOAD FIRMWARE from one fixture to all x.Spot fixtures on the link:
1. Disconnect or bypass any controllers, serial data distributors, data line
optoisolators, and any fixtures using RS-422 communications (such as
Dataflash
®
AF1000 xenon strobes, and Intellabeam
®
fixtures). These devices will
block communication between the crossloading fixture and any other x.Spot
fixtures on the link.
