4-6 The x.Spot Menu System x.Spot™ User Manual
* Before another Boost or Lightning effect can occur, the Shutter channel must
be moved to either closed or open, or the Lamp Function channel must be
moved outside the Lamp Effects range.
Dim
The Dim parameter is controlled with DMX Channel 7. The Dim parameter provides
full mechanical dimming capability without changing the color temperature or the
beam shape. The dim values range from closed (DMX value of 0) to fully open (DMX
value of 255). The Lamp Function channel, (see page 4-4), can be set to control
whether the Dimming is accomplished by lower lamp power (electronic), closing the
shutter (mechanical) or both (dual dimming). Table 4-2 describes the interaction
between the Lamp Function, Shutter and Dim Channels.
Values 64-95
Lamp Effects
Close Closes shutter
Periodic strobes
Strobes are mechanical and will go to black.Random/random strobes
Synchronous/random strobes
Boost lamp*, black. Six time
ranges from 1–.25 second
Boosts the lamp for a specified time then closes
the shutter.
Boost lamp*, white. Six time
ranges from 1–.25 second
Boosts the lamp for a specified time, then leaves
the shutter open with the lamp dimmed.
Lightning strike* Six available
for x.Spot fixtures
Dim channel scales the overall brightness of the
lightning effect.
Open Opens shutter
Values 96-127
Dual Dimming
Closed The lamp electronically dims with the output
ranging from a minimum–700W. as the
mechanical dimming goes from 0%–100%.
Open
Values 128-159
Electronic
Dimming™
Close
The shutter functions are the same as the
normal shutter function range.
Strobing and Dimming is accomplished
electronically by adjusting the lamp power.
Dimming will not go to black.
Periodic Strobe
Random/Random Strobe
Random/Synchronous Strobe
Ramp Open/Snap Shut
Snap Open/Ramp Shut
Ramp Open/Ramp Shut
Random Ramp/Snap
Random Snap/Ramp
Open
Table 4-2 Lamp Control and Shutter Parameter Settings
Lamp Function
Setting
Shutter Setting Description
