2-4 Setup and Configuration x.Spot™ User Manual
X.Spot fixtures are designed for 3- or 4-point installation on standard 12, 16 or
181/2 in. truss and are easily adapted for intelligent (retractable) truss mounting.
Figure 2-3 shows some basic mounting options.
Figure 2-3 Baseplate configuration for standard truss sizes
254.0mm
10.0in
127 mm
5.0 in
342.9mm
13.5in
171.5mm
6.75in
13.5mm
.53in
470.0mm
18.50in
235.0mm
9.25in
470.0 mm
18.5in
235.0mm
9.25in
406.5mm
16.0in
406.5mm
16.0in
12in x 18in Light Duty
20.5in x 20.5in Medium Duty
Single Pipe Mounting
12in x 12in Light Duty
Single Pipe Mounting with optional brackets
