3-24 Fixture Operation x.Spot™ User Manual
2. Using the left and right arrows on the Navigation button, scroll to the
TEST OPTIONS MENU and press the Enter button to select.
3. Using the left and right arrows on the Navigation button, scroll to the COPY BOOT
option and press the Enter button to select.
4. Use the up and down arrows on the Navigation button to scroll to the YES option
and then press the Enter button to store the command. The fixture will store the
new boot code, then automatically home.
Self Test Menu
This option displays the steps and DMX values generated as the fixture tests the
motor operation of various functions and wheels. Self test can be run and viewed on
all the fixture parameters sequentially, or individual parameters. Table 3-3 shows the
available self tests on each slot of a standard configuration x.Spot fixture.
To access the SELF TEST MENU:
1. Press the Menu button to unlock the menu system or to move back up the system
to the top level menus.
2. Use the left and right arrows on the Navigation button to scroll to the
TEST OPTIONS MENU and press the Enter button to select.
3. Use the left and right arrows on the Navigation button to scroll to ALL or an
individual parameter’s Slot location and press the Enter button to select.
4. If ALL is selected, the fixture begins running the self tests sequentially.
5. If a Slot is selected, use the up and down arrows on the Navigation button to
scroll to a specific parameter and press the Enter button to view that parameter’s
self test.
Table 3-3 Self Test by Slot
Chassis Slot 1 Slot 2 Slot 3
Pan Static Color Gobo 1 Gobo 2
Tilt Cyan Gobo 1 Rotate Gobo 2 Rotate
Dim Magenta Effect Iris
Frost Yellow Effect Rotate
Focus CTO
Zoom CTB
