x.Spot ™User Manual General Maintenance 6-1
6
Chapter 6:
Troubleshooting
This chapter lists typical symptoms and solutions for problems you might experience
when using x.Spot fixture. For additional help contact Customer Service for assistance,
see “Contacting High End Systems®” on page ii.
Caution: This fixture must be serviced by qualified personnel. The information
listed in this section is intended to assist qualified personnel only.
LED States
LEDs located throughout the x.Spot indicate how the unit is functioning. Table 6-1 lists
LED States, and problems they may indicate.
Table 6-1 LED State
Location LED # State Problem? Description
2-phase board LD1-
LD4
Green No S1-S4 sensor open
Yellow No S1-S4 sensor closed
Flashing red No Board is initializing
Infinitely
flashing red
Yes Board not receiving data
Red Yes Board not receiving data
Flashing red
and green
Yes Addressing screw(s) missing from board
Sporadically
flashing
green &
yellow
Yes 2 boards are addressed the same.
(Corrected by adding addressing screw to
appropriate location)
OFF Yes Board not receiving power
LD5 Green No Receiving proper voltage
Dim green Yes Board not receiving data
OFF Yes Board not receiving power
