High End Systems x.Spot - Specifications; Physical Specifications; Figure 1-3 X-Spot Dimensions

x.Spot ™ User ManualFeatures and Specifications1-5
1
Specifications
Physical Specifications
Height: 814.5mm (32.0 in)
Width: 521mm (20.6 in)
Depth: 520.8mm (20.5in)
Weight: 31.8kg (70lb)
Figure 1-3 x-Spot Dimensions
254mm
(10.0in)
343mm
(13.5in)
235mm
(9.25in)
470mm
(18.5in)
470mm
(18.5in)
413mm
(16.25in
557mm
(21.9in)
533mm
(21in)
140mm
(5.5in)
472mm
(18.6in)
125mm
(4.9in)
367mm
(14.4in)
426mm
(16.8in)
814mm
(32.0in)
178mm
(7.0 in)
260mm
(10.25in
521mm
(20.5in)
523mm
(20.6in)
142mm
(5.6in)
172mm
(6.75in)
