x.Spot ™User Manual x.Spot DMX Protocol A-1
A
Appendix A:
x.Spot™ DMX Protocol
Chan
#
Parameter Description
Value
(dec.)
Value
(%)
Value
(hex)
BASIC FIXTURE FUNCTIONS
1 Pan Coarse
Coarse-adjusts pan to approximately 2
degrees of desired position
0-255 0-100 00-FF
2Pan Fine
Fine-adjusts pan position in increments less
than 1 degree
0-255 0-100 00-FF
3 Tilt Coarse
Coarse-adjusts tilt to approximately 2
degrees of desired position
0-255 0-100 00-FF
4 Tilt Fine
Fine-adjusts tilt position in increments less
than 1 degree
0-255 0-100 00-FF
5 Lamp Function
Normal Shutter Functions 0-31 0-12 00-1F
Lamp Assisted Strobes boosts the Lamp
above 700 Watts for periodic and random
strobes set in Shutter channel 6.
32-63 13-25 20-3F
Lamp Effects boosts the lamp above 700
watts for Boost to White, Boost to Black, or
Lightning effects set in Shutter channel 6.
64-95 35-37 40-5F
Dual Dimming adds electronic dimming to the
mechanical dimming set in the Dim channel 7.
(0%–100%)
96-127 38-50 60-7F
Electronic Dimming Only Lamp output varies
from a minimum–700W; does not go to black
128-159 50-62 80-9F
Reserved 160-191 63-75 A0-BF
Reserved 192-223 75-88 C0-DF
Normal Shutter Functions 224-255 88-100 E0-FF
6
Shutter, Normal
Function
Lamp Function
channel set from
0-31
Close 0-23 0-9 00-17
Periodic Strobe (variable) 24-49 9-19 18-31
Random/Random Strobe (variable) 50-75 20-29 32-4B
Random/Synchronous Strobe (variable) 76-101 30-40 4C-65
Ramp Open/Snap Shut (variable) 102-127 40-50 66-7F
Snap Open/Ramp Shut (variable) 128-153 50-60 80-99
Ramp Open/Ramp Shut (variable) 154-179 60-70 9A-B3
Random Ramp/Snap (variable) 180-205 71-80 B4-CD
Random Snap/Ramp (variable) 206-231 81-91 CE-E7
Open 232-255 91-100 E8-FF
