A-2 x.Spot DMX Protocol x.Spot ™User Manual
6
Shutter, Lamp
Assisted Strobes
Lamp Function
channel set from
32–63
Close 0-23 0-9 00-17
Periodic Strobe (variable, Lamp assisted) 24-49 9-19 18-31
Random/Rand Strobe (variable, Lamp
assisted)
50-75 20-29 32-4B
Random/Sync (variable, Lamp assisted) 76-101 30-40 4C-65
Ramp Open/Snap Shut (variable) 102-127 40-50 66-7F
Snap Open/Ramp Shut (variable) 128-153 50-60 80-9A
Ramp Open/Ramp Shut (variable) 154-179 60-70 9A-B3
Random Ramp/Snap (variable) 180-205 71-80 B4-CD
Random Snap/Ramp (variable) 206-231 81-91 CE-E7
Open 232-255 91-100 E8-FF
Shutter, Lamp
Effect
Lamp Function
channel set from
64–95
Close 0-23 0-9 00-17
Periodic lamp strobes 24-49 9-19 18-31
Random random lamp strobes 50-75 20-29 32-4B
Synchronous random lamp strobes 76-101 30-40 4C-65
Boost lamp 1.0 second, black 102-105 40-41 66-69
Boost lamp 0.75 second, black 106-109 42-43 6A-6D
Boost lamp 0.66 second, black 110-113 43-44 6E-71
Boost lamp 0.5 second, black 114-117 45-46 72-75
Boost lamp 0.33 second, black 118-121 46-47 76-79
Boost lamp 0.25 second, black 122-127 48-50 7A-7F
Boost lamp 1.0 second, white 128-131 50-51 80-83
Boost lamp 0.75 second, white 132-135 52-53 84-87
Boost lamp 0.66 second, white 136-139 53-55 88-8B
Boost lamp 0.50 second, white 140-143 55-56 8C-8F
Boost lamp 0.33 second, white 144-147 56-58 90-93
Boost lamp 0.25 second, white 148-153 58-60 94-99
Lightning strike 1 154-157 60-62 9A-9D
Lightning strike 2 158-161 62-63 9E-A1
Lightning strike 3 162-165 64-65 A2-A5
Lightning strike 4 166-169 65-66 A6-A9
Lightning strike 5 170-173 67-68 AA-AD
Lightning strike 6 174-179 68-70 AE-B3
Reserved. Default Black. 180-231 71-91 B4-E7
Open 232-255 91-100 E8-FF
Chan
#
Parameter Description
Value
(dec.)
Value
(%)
Value
(hex)
