x.Spot ™User Manual x.Spot DMX Protocol A-3
A
6
Shutter,
Electronic
Dimming:
Lamp Function
channel set from
128-159
Close 0-23 0-9 00-17
Periodic Strobe (variable) 24-49 9-19 18-31
Random/Rand Strobe (variable) 50-75 20-29 32-4B
Random/Sync (variable) 76-101 30-40 4C-65
Ramp Open/Snap Shut (variable) 102-127 40-50 66-7F
Snap Open/Ramp Shut (variable) 128-153 50-60 80-99
Ramp Open/Ramp Shut (variable) 154-179 60-70 9A-B3
Random Ramp/Snap (variable) 180-205 71-80 B4-CD
Random Snap/Ramp (variable) 206-231 81-91 CE-E7
Open 232-255 91-100 E8-FF
7Dim
Mechanical dimming only, from closed–open 0-255 0-100 00-FF
Mechanical + electronic dimming from
closed–open Lamp Control channel 5 set
from 96–127
0-255 0-100 00-FF
8Frost
Open (No Frost) 0 0 00
Variable Frost (open to closed) 1-127 1-49 01-7F
Full Frost 128-135 50-53 80-87
Periodic Frost Strobe (slow to fast) 136-151 53-59 88-97
Random Frost Strobe (slow to fast) 152-167 60-66 98-A7
Ramp Open/Snap Shut 168-183 66-72 A8-B7
Snap Open/Ramp Shut 184-199 72-78 B8-C7
Ramp Open/Ramp Shut 200-215 78-84 C8-D7
Random Ramp/Snap 216-231 85-91 D8-E7
Random Snap/Ramp 232-247 91-97 E8-F7
Open (No Frost) 248-255 97-100 F8-FF
9 Focus Function
ZoomTrack 0-31 0-12 00-1F
Manual Focus 32-63 13-24 20-3F
Reserved 64-95 25-37 40-5F
Reserved 96-127 38-49 60-7F
Reserved 128-159 50-62 80-9F
Reserved 160-191 63-74 A0-BF
Reserved 192-223 75-87 C0-DF
Reserved 224-255 88-100 E0-FF
10 Focus
Auto or Manual Focus In 0 0 00
Auto or Manual Focus Out 255 100 FF
11 Zoom
Zoom in 0 0 00
Zoom out 255 100 FF
12 MSpeed (see “MSpeed Conversion Table in Appendix B)
Chan
#
Parameter Description
Value
(dec.)
Value
(%)
Value
(hex)
