A-4 x.Spot DMX Protocol x.Spot ™User Manual
13
Macro
(MacroSpeed
controlled via
Mspeed)
Macro Off 0-5 0-2 00-05
Pan sweep from small to large angle 6-62 2-24 06-3E
Macro Off 63-65 25-26 3F-41
Tilt sweep from small to large angle 66-122 26-48 42-7A
Macro Off 123-125 48-49 7B-7D
Clockwise circle from small to large 126-160 49-63 7E-A0
Macro Off 161-163 63-64 A1-A3
Counterclockwise circle from small to large 164-198 64-78 A4-C6
Reserved 199-255 78-100 C7-FF
14
Control
(Set Shutter
Channel to “0” to
access Control
channel settings
except for Pan/Tilt)
Safe 0-9 0-4 00-09
Pan and Tilt Mspeed Off 10-19 4-8 0A-13
Display Off 20-28 8-11 14-1C
Display Dim 30-38 12-15 1E-26
Display Bright 40-48 16-19 28-30
Home All 60-68 24-27 3C-44
Lamp On 80-88 31-35 50-58
Lamp Off 90-98 35-38 5A-62
Shutdown 120-130 47-51 78-82
Reserved 131-149 51-58 83-95
Home Pan/Tilt 160-168 63-66 A0-A8
Home Color System 170-178 67-70 AA-B2
Home Gobo System 180-188 70-74 B4-BC
Home Strobe/Dim 190-198 75-78 78-C6
Home Focus/Zoom/Frost 200-208 78-82 C8-D0
Home Iris 210-218 82-86 D2-DA
Chan
#
Parameter Description
Value
(dec.)
Value
(%)
Value
(hex)
