x.Spot ™User Manual x.Spot DMX Protocol A-5
A
SLOT 1: SIX-WHEEL COLOR MIXING MODULE
15
Static Color
Function
Full Speed Control
Indexed 0 - 15 0-6 0-0F
Forward Spin 16-31 6-12 10-1F
Reverse Spin 32-47 13-18 20-2F
Continuous 48-63 19-25 30-3F
Slow Scan 64-79 25-31 40-4F
Fast Scan 80-95 31-37 50-5F
Random 96-111 38-44 60-6F
Blink-Indexed 112-127 44-50 70-7F
MSpeed Control
Indexed 128-143 50-56 80-8F
Forward Spin 144-159 57-62 90-9F
Reverse Spin 160-175 63-69 A0-AF
Continuous 176-191 69-75 B0-BF
Slow Scan 192-207 75-81 C0-CF
Fast Scan 208-223 82-88 D0-DF
Random 224-239 88-94 E0-EF
Blink 240-255 94-100 F0-FF
16
Static Color
Position
Indexed, Scan, and Blink Modes
Color Position 1 Open (White) 0-23 0-9 0-17
Position 1|2 24-42 2-17 18-2A
Position 2 43-61 17-24 2B-3D
Position 2|3 62-80 24-31 3E-50
Position 3 81-99 32-38 51-62
Position 3|4 100-118 39-46 63-76
Position 4 119-137 47-54 77-89
Position 4|5 138-156 54-61 8A-9C
Position 5 157-175 62-69 9D-AF
Position 5|6 176-194 69-76 B0-C2
Position 6 195-213 77-84 C3-D5
Position 6|1 214-232 84-91 D6-E8
Position 1 Open (White) 233-255 91-100 E9-FF
Spin Mode
Spin Stop 0 0 0
Forward Spin Slowest to Fastest 4-255 2-100 .04-FF
Reverse Spin Slowest to Fastest 4-255 2-100 .04-FF
Random Mode
Random Stop 0 2-100 .04-FF
Random Slowest to Fastest 4-255 2-100 .04-FF
Continuous Mode
Positioning from 0-360 degrees 0-255 0-100 0-FF
Chan
#
Parameter Description
Value
(dec.)
Value
(%)
Value
(hex)
