A-6 x.Spot DMX Protocol x.Spot ™User Manual
17
Mix Color
Function
Full Speed Control
Pure Mix 0-15 0-6 0-0F
Continuous 16-31 6-12 10-1F
Reserved 32-47 13-18 20-2F
Spin (Wheel Spin speed, direction, or fixed
position set individually on CYM channels.)
48-63 19-25 30-3F
Cycle (Rate set by Cyan channel) 64-79 25-31 40-4F
Reserved 80-95 31-37 50-5F
Random (Rate set by Cyan channel.) 96-111 38-44 60-6F
Blink (Defined using Continuous wheel
operation)
112-127 44-50 70-7F
MSpeed Control
Pure Mix 128-143 50-56 80-8F
Continuous 144-159 57-62 90-9F
Reserved 160-175 63-69 A0-AF
Spin (Wheel Spin speed, direction, or fixed
position set individually on CYM channels.)
176-191 69-75 B0-BF
Cycle (Rate set by Cyan channel) 192-207 75-81 C0-CF
Reserved 208-223 82-88 D0-DF
Random (Rate set by Cyan channel.) 224-239 88-94 E0-EF
Blink 240-255 94-100 F0-FF
18 Cyan
Pure Mix Mode
Full Cyan 0 0 00
Open 255 100 FF
Continuous and Blink Modes
Full Cyan 0 0 0
Open 127 50 7F
Full Cyan 1285080
Open 255 100 FF
Spin Mode
Continuous Positioning 0-127 0-50 00-7F
Reverse Spin fastest 128-157 50-62 80-9D
Reverse Spin slowest 158-187 62-73 9E-BB
Spin Stop 188-195 74-77 BC-C3
Forward Spin slowest 196-225 77-88 C4-E1
Forward Spin fastest 226-255 89-100 E2-FF
Cycle and Random Modes
Slow Rate 0 0 00
Fast Rate 255 100 FF
Chan
#
Parameter Description
Value
(dec.)
Value
(%)
Value
(hex)
