x.Spot ™User Manual x.Spot DMX Protocol A-7
A
19 Magenta
Pure Mix Mode
Full Magenta 0 0 00
Open 255 100 FF
Continuous and Blink Modes
Full Magenta 0 0 0
Open 127 50 7F
Full Magenta 128 50 80
Open 255 100 FF
Spin Mode
Continuous Positioning 0-127 0-50 00-7F
Reverse Spin fastest 128-157 50-62 80-9D
Reverse Spin slowest 158-187 62-73 9E-BB
Spin Stop 188-195 74-77 BC-C3
Forward Spin slowest 196-225 77-88 C4-E1
Forward Spin fastest 226-255 89-100 E2-FF
20 Yellow
Pure Mix Mode
Full Yellow 0 0 00
Open 255 100 FF
Continuous and Blink Modes
Full Yellow 0 0 0
Open 127 50 7F
Full Yellow 128 50 80
Open 255 100 FF
Spin Mode
Continuous Positioning 0-127 0-50 00-7F
Reverse Spin fastest 128-157 50-62 80-9D
Reverse Spin slowest 158-187 62-73 9E-BB
Spin Stop 188-195 74-77 BC-C3
Forward Spin slowest 196-225 77-88 C4-E1
Forward Spin fastest 226-255 89-100 E2-FF
21
Color
Temperature
Orange
Always in Continuous Mode
Open 0 0 0
Full CTO 170 67 AA
Beam flatten 213 84 D5
Open 255 100 FF
22
Color
Temperature Blue
Always in Continuous Mode
Beam flatten 0 0 0
Open 43 17 2B
Full CTB 213 84 D5
Beam flatten 255 100 FF
Chan
#
Parameter Description
Value
(dec.)
Value
(%)
Value
(hex)
