A-8 x.Spot DMX Protocol x.Spot ™User Manual
SLOT 2: DUAL ROTATING GOBOS MODULE
23 Gobo1 Function
Full Speed Control
Indexed 0 - 15 0-6 0-0F
Forward Wheel Spin 16-31 6-12 10-1F
Reverse Wheel Spin 32-47 13-18 20-2F
Scan 48-63 19-25 30-3F
Random 64-79 25-31 40-4F
Blink 80-95 31-37 50-5F
TBC 96-111 38-44 60-6F
Continuous 112-127 44-50 70-7F
MSpeed Control
Indexed 128-143 50-56 80-8F
Forward Wheel Spin 144-159 57-62 90-9F
Reverse Wheel Spin 160-175 63-69 A0-AF
Scan 176-191 69-75 B0-BF
Random 192-207 75-81 C0-CF
Blink 208-223 82-88 D0-DF
TBC 224-239 88-94 E0-EF
Continuous 240-255 94-100 F0-FF
24 Gobo 1 Position.
Indexed /Blink/Scan Modes
Position 1 (Open) 0-15 0-6 0-0F
Position 2 16-47 6-18 10-2F
Position 3 48-79 19-31 30-4F
Position 4 80-111 31-44 50-6F
Position 5 112-143 44-56 70-8F
Position 6 144-175 57-69 90-AF
Position 7 176-207 69-81 B0-CF
Position 8 208-239 82-94 D0-EF
Position 1 (Open) 240-255 94-100 F0-FF
Spin Mode
Spin Stop 0-3 0-1 0-3
Spin Forward Slowest to Fastest 4-255 2-100 4-FF
Spin Reverse Slowest to Fastest 4-255 2-100 4-FF
Random Mode
Random Stop 0-3 0-1 0-3
Random Slowest to Fastest 4-255 2-100 4-FF
Continuous Mode
Positioning from 1-360 degrees 0-255 100 FF
Chan
#
Parameter Description
Value
(dec.)
Value
(%)
Value
(hex)
