x.Spot™ User Manual Fixture Operation 3-15
3
2. Using the left and right arrows on the Navigation button, scroll through the top
level to ONBOARD PRESETS MENU and press the Enter button to select.
3. Using the left and right arrows on the Navigation button, scroll to DEFAULT
PRESETS.
4. Use the up and down arrows on the Navigation button to scroll to YES to reset the
default presets or NO to leave current programming. Press the Enter button to
select.
Send Presets to Other Fixtures
This menu options sends the values programmed for all 16 scenes of a User Mode on
one x.Spot fixture to all other x.Spot fixtures on a DMX link. This menu option can
be accessed for either User A or User B. To change User Mode, see “Select User
Mode” on page 3-20.
To send a scene’s parameter setting to other fixtures:
1. Disconnect or bypass any controllers, serial data distributors, data line
optoisolators, and any fixtures using RS-422 communications (such as
Dataflash
®
AF1000 xenon strobes, and Intellabeam
®
fixtures). These devices will
block communication between x.Spot fixtures on the link.
2. Press the Menu button to unlock the menu system or to move back up the system
to the top level menus.
3. Using the left and right arrows on the Navigation button, scroll through the top
level to ONBOARD PRESETS MENU and press the Enter button to select
4. Using the left and right arrows on the Navigation button, scroll to SEND PRESETS
TO FIXTURES?XXX.
5. Use the up and down arrows on the Navigation button to scroll to YES to SEND
PRESETS and press the Enter button to select. The fixture sends presets for that
scene to all x.Spots on the link and returns DONE when action is complete.
