Display Error Messages
8 Character
Error Message
16 Character Error
Message
Location
Problem/Procedure
For replacement parts, see “Contacting High End Systems®” on page ii
LAMPFAN1
LAMP FAN 1
STOPPED
Lamp fan on side with tilt board.
Connects to Tilt board HD9.
Fan is not operating:
1. Check wiring connections at fan and board.
2. Verify board operation by switching it with another 3-phase board
from the fixture, see “Replacing a Driver Board” on page 5-6.
3. Check for wire harness damaged or dead fan motor
LAMPFAN2
LAMP FAN 2
STOPPED
Lamp fan on side opposite tilt
board. Connects to Tilt board
HD3.
OPTCFAN
OPTICS FAN
STOPPED
Optics fan. Connects to Tilt board
HD4.
TOPBFAN1
TOP BOX FAN 1
STOPPED
Motor power supply fan.
Connects to Pan board HD4
TOPBFAN2
TOP BOX FAN 2
STOPPED
Lamp power supply fan.
Connects to Pan board HD3.
LMP1TEMP
HEAD TEMP 1
MISSING
Temp sensor on tilt board side.
Connects to Tilt board HD5.
Temperature sensor is not operating:
1. Check wiring connections at temp sensor and board .
2. Check for wire damage or dead fan.
LMP2TEMP
HEAD TEMP 2
MISSING
Temp sensor on side away from
Tilt board. Connects to Tilt board
HD10 .
TOPTEMP
TOP BOX TEMP
MISSING
Top box motor power supply fan.
Connects to HD10 on Pan board.
