High End Systems x.Spot - Electrical Specifications; Environmental Specifications; Dichroic, Litho, and Effect Specifications; Lamp Specifications

1-6 Features and Specifications x.Spot™ User Manual
Electrical Specifications
Warning: Class 1 equipment - This equipment must be earthed.
Selectable voltages: Universal Input from 100–230 VAC, (50–60Hz)
Rated power: 1200 W
Fuses: Motor power supply output: 2.5A, 250V slow blow only.
2- and 3-phase driver boards: 2.5A, 125 V, Slow Blow SMF
One external main fuse: 15A, 250V slow blow only
Environmental Specifications
Maximum ambient temperature, (T
a
): 50° C (122°F)
Maximum exterior surface temperature: 130° C (266°F)
Minimum distance to flammable objects: 1m (3.28ft)
Minimum distance to lighted object: 2m (6.56ft)
Do not mount on a flammable surface.
Dichroic, Litho, and Effect Specifications
Dichroic Glass
• Thickness: 1.8 mm ± 0.25 mm (0.069in ± 0.010in)
LithoPatterns
• Diameter: 36.45mm ± 0.13 mm (1.435in ± .006)
• Image area: 31.75mm ± 0.25 mm (1.250in ± 0.010in)
• Thickness (rotating litho): 1.78mm ± 0.13 mm (.070 in ± .006)
• Thickness (static litho):1.78mm ± 0.13 mm (.070 in ± .006)
Effect Glass
• Diameter: 36.45mm ± 0.13 mm (1.435in ± .006)
• Image area: 31.75mm ± 0.25 mm (1.250in ± .010)
• Maximum thickness: 3.81mm (.150 in)
Lamp Specifications
• Lamp type: Philips MSR700SA 700W short arc
• Color temperature: 5600 K
• Life: 500 hours
