x.Spot ™User Manual x.Spot DMX Protocol A-13
A
35
Gobo 2 Rotate
Function
Full Speed Control
Indexed 0-15 0-6 0-0F
Forward Rotate 16-31 6-12 10-1F
Reverse Rotate 32-47 13-18 20-2F
Scan 48-63 19-25 30-3F
Blink 64-79 25-31 40-4F
Reserved 80-95 31-37 50-5F
Reserved 96-111 38-44 60-6F
Reserved 112-127 44-50 70-7F
MSpeed Control
Indexed 128-143 50-56 80-8F
Forward Rotate 144-159 57-62 90-9F
Reverse Rotate 160-175 63-69 A0-AF
Scan 176-191 69-75 B0-BF
Blink 192-207 75-81 C0-CF
Reserved 208-223 82-88 D0-DF
Reserved 224-239 88-94 E0-EF
Reserved 240-255 94-100 F0-FF
36
Gobo 2 Rotate
Coarse
Indexed/Blink Modes
Position from 0-360 degrees 0-255 0-100 0-FF
Continuously Variable Forward Rotate Mode
Rotate Stop 0-3 0-1 0-3
Forward Rotate Slowest to Fastest 4-255 2-100 4-FF
Reverse Rotate Slowest to Fastest 4-255 2-100 4-FF
Scan Mode
Scan Slowest to Fastest 0-255 0-100 0-FF
37
Gobo 2 Rotate
Fine
Indexed Mode
Low Order Byte position from 0-360 degrees 0-255 0-100 0-FF
38 Iris
Closed 0 0 0
Variable Iris 1-127 1-50 01-7F
Open 128-135 50-53 80-87
Periodic Strobe (Variable) 136-151 53-59 88-97
Random Strobe (Variable) 152-167 60-66 98-A7
Ramp Open/Snap Shut (Variable) 168-183 66-72 A8-B7
Snap Open/Ramp Shut (Variable) 184-199 72-78 B8-C7
Ramp Open/Ramp Shut (Variable) 200-215 78-84 C8-D7
Random Ramp/Snap (Variable) 216-231 85-91 D8-E7
Random Snap/Ramp (Variable) 232-247 91-97 E8-F7
Open 248-255 97-100 F8-FF
Chan
#
Parameter Description
Value
(dec.)
Value
(%)
Value
(hex)
