D-2 Menu Map x.Spot ™User Manual
DMX Address Menu
Level 2 Option/Setting Description/Notes
enters and exits
Menu System
scrolls between values selects
SET DMX START
CHANNEL: ###
1-498
Selected value becomes the first DMX value in the range for
that fixture on a DMX 512 link.
Onboard Presets Menu
L e v e l 2 L e v e l 3 L e v e l 4 O p t i o n / S e t t i n g D e s c r i p t i o n / N o t e s
enters and exits Menu System and moves up levels
moves between items on the same level. selects
scrolls between values selects
PLAYBACK MODE
MENU
PLAYBACK MODE
ON
Plays the currently programmed sequence of scenes up to 16 scenes or
until it reaches a zeroed scene
OFF
Turns Playback off
SCENE PLAYING:
Displays the scene # currently playing when PLAYBACK MODE is ON
EDIT SCENE##
1–16
Selects scene 1-16 in the current User Mode to edit
CHASSIS MENU
SHUTTER
(Options with all LAMP
FUNCTION
settings)
OPEN 255
Opens shutter and displays DMX value of 232 or 255
CLOSE 0
Closes shutter and displays related DMX value of 0
PERIODIC ## ### Sets Periodic beam strobing rates from 1–26 with DMX value
RANDOM ## ### Sets Random beam strobing rates from 1–26 with DMX value
RAND/SYNC ## ###
Sets Synchronized random strobing of all x.Spot fixtures using the same
controller
at strobe rates from 1–26 with DMX value
SHUTTER
(Options only with
LAMP FUNCTION
setting at NORMAL or
LAMP STROBE)
RAMP/SNAP ## ###
Set strobe rate from 1–26 with DMX value to open shutter at variable
speeds, then snap shut at full speed
SNAP/RAMP ## ###
Set strobe rate from 1–26 with DMX value to open shutter at full speed,
then ramp shut
RAMP/RAMP ## ###
Set strobe rate from 1–26 with DMX value to open shutter at variable
speeds, then ramp shut
RNDRMPSNP ## ###
Set strobe rate from 1–26 with DMX value to open shutter at random
variable speeds, then snaps shut at full speed
RNDSNPRMP ## ###
Set strobe rate from 1–26 with DMX value to open shutter at full speed,
then ramp shut at random variable speeds
