Trackspot User Manual
Specifications
Intro-5
Environmental Specifications
Maximum ambient temperature, Ta: 50° C (122° F)
Maximum exterior surface temperature: 67° C (153° F)
Minimum distance to lighted object: 1.0 meter (3.28 ft)
Minimum distance to flammable objects: 1.0 meter (3.28 ft)
Caution: Use in dry locations only.
Warning: Do not mount on a flammable surface.
Cable and Connector Specifications
DMX data cables
Belden
®
9841 or equivalent (meets specifications for EIA RS-485
applications) with the following characteristics:
• 2-conductor twisted pair plus a shield
• maximum capacitance between conductors - 30 pF/ft.
• maximum capacitance between conductor and shield - 55 pF/ft.
• maximum resistance of 20 / 1000 ft.
• nominal impedance 100-140
DMX data connectors
3-pin male and female XLR connectors
DMX data terminators
Male XLR connector with 120 ohm terminator
Safety Specifications
Safety standards: EN 60598-1 : 1993
EN 60598-2-17 : 1989
A1-A3 : 1993
EMC standards: EN 55022, Class A ITE
IEC 801-2, 1991 Level 2 (4/8 kV)
IEC 801-3, Draft 5 Level 2 (3 V/m)
IEC 801-4, 1988 Level 2 (1 kV/0.5 kV)
UL 153
CSA 22.2 No. 12
