C-2
Address Switch Settings
Trackspot User Manual
Address Switch Settings
Address switch settings for LWR protocol and master/slave mode are
listed below. Address switch settings for DMX 512 protocol are listed
in Table A-1 on page A-2. When using standard analog control, set all
address switches OFF on all fixtures.
Table C-2. Address switch settings for LWR protocol and
master/slave mode
Fixture Number Address Switches ON
01
All switches OFF (used
with LWR protocol only)
02 1
03 2
04 1, 2
05 3
06 1, 3
07 2, 3
08 1, 2, 3
09 4
10 1, 4
11 2, 4
12 1, 2, 4
13
3, 4
14 1, 3, 4
15 2, 3, 4
16 1, 2, 3, 4
17 5,
18 1, 5
19 2, 5
20 1, 2, 5
21 3, 5
22 1, 3, 5
23 2, 3, 5
24 1, 2, 3, 5
