Personality Switch Settings
C-1
C
Appendix C
Personality and Address Switch
Settings
Personality Switch Settings
Table C-1. Personality switch settings for all control modes and
operating modes
Mode
Personality
Switches ON
Self Test 1
Set Up (Focus) 2
Lamp Save 1, 2
Auto Dim Override (LWR) 3, 4, 5
Pan Invert 6
Tilt Invert 7
Low Resolution DMX 512 mode (channels 1-256) 5
Low Resolution DMX-512 mode (channels 257-512) 4
High Resolution DMX 512 mode (channels 1-256) 3, 5
High Resolution DMX 512 mode (channels 257-512) 3, 4
LWR protocol and normal run All switches OFF
Standard Analog 4, 5
Stand Alone (Audio Master) 8
Stand Alone (Audio Slave) 3
