High End trackspot - Table A-1. Starting Channels in 7-Channel DMX 512 Protocol

A-2
Start Channels and Construct Parameters
Trackspot User Manual
Table A-1. Starting channels in 7-channel DMX 512 protocol
Numerical
Order In
Link
Address
DIP Switches
ON
Personality DIP
Switches ON
Low High
Resolution Resolution
DMX
Starting
Channel
Fixture 1 none 5 3, 5 001
Fixture 2 1, 2, 3 5 3, 5 008
Fixture 3 2, 3, 4 5 3, 5 015
Fixture 4 1, 3, 5 5 3, 5 022
Fixture 5 3, 4, 5 5 3, 5 029
Fixture 6 1, 2, 6 5 3, 5 036
Fixture 7 2, 4, 6 5 3, 5 043
Fixture 8 1, 5, 6 5 3, 5 050
Fixture 9 4, 5, 6 5 3, 5 057
Fixture 10 1, 2, 3, 4, 5, 6 5 3, 5 064
Fixture 11 2, 3, 7 5 3, 5 071
Fixture 12 1, 3, 4, 7 5 3, 5 078
Fixture 13 3, 5, 7 5 3, 5 085
Fixture 14 1, 2, 4, 5, 7 5 3, 5 092
Fixture 15 2, 6, 7 5 3, 5 099
Fixture 16 1, 4, 6, 7 5 3, 5 106
Fixture 17 5, 6, 7 5 3, 5 113
Fixture 18 1, 2, 3, 5, 6, 7 5 3, 5 120
Fixture 19 2, 3, 4, 5, 6, 7 5 3, 5 127
Fixture 20 1, 3, 8 5 3, 5 134
Fixture 21 3, 4, 8 5 3, 5 141
Fixture 22 1, 2, 5, 8 5 3, 5 148
Fixture 23 2, 4, 5, 8 5 3, 5 155
Fixture 24 1, 6, 8 5 3, 5 162
Fixture 25 4, 6, 8 5 3, 5 169
Fixture 26 1, 2, 3, 4, 6, 8 5 3, 5 176
Fixture 27 2, 3, 5, 6, 8 5 3, 5 183
Fixture 28 1, 3, 4, 5, 6, 8 5 3, 5 190
Fixture 29 3, 7, 8 5 3, 5 197
Fixture 30 1, 2, 4, 7, 8 5 3, 5 204
Fixture 31 2, 5, 7, 8 5 3, 5 211
Fixture 32 1, 4, 5, 7, 8 5 3, 5 218
Fixture 33 6, 7, 8 5 3, 5 225
Fixture 34 1, 2, 3, 6, 7, 8 5 3, 5 232
Fixture 35 2, 3, 4, 6, 7, 8 5 3, 5 239
Fixture 36 1, 3, 5, 6, 7, 8 5 3, 5 246*
Fixture 37 none 4 3, 4 257
