Trackspot User Manual
Start Channels and Construct Parameters
A-3
A
*Note: Channels 253 - 256 and channels 509 - 512 cannot be used
due to Trackspot’s 7-channel block structure.
Fixture 38 1, 2, 3 4 3, 4 264
Fixture 39 2, 3, 4 4 3, 4 271
Fixture 40 1, 3, 5 4 3, 4 278
Fixture 41 3, 4, 5 4 3, 4 285
Fixture 42 1, 2, 6 4 3, 4 292
Fixture 43 2, 4, 6 4 3, 4 299
Fixture 44 1, 5, 6 4 3, 4 306
Fixture 45 4, 5, 6 4 3, 4 313
Fixture 46 1, 2, 3, 4, 5, 6 4 3, 4 320
Fixture 47 2, 3, 7 4 3, 4 327
Fixture 48 1, 3, 4, 7 4 3, 4 334
Fixture 49 3, 5, 7 4 3, 4 341
Fixture 50 1, 2, 4, 5, 7 4 3, 4 348
Fixture 51 2, 6, 7 4 3, 4 355
Fixture 52 1, 4, 6, 7 4 3, 4 362
Fixture 53 5, 6, 7 4 3, 4 369
Fixture 54 1, 2, 3, 5, 6, 7 4 3, 4 376
Fixture 55 2, 3, 4, 5, 6, 7 4 3, 4 383
Fixture 56 1, 3, 8 4 3, 4 390
Fixture 57 3, 4, 8 4 3, 4 397
Fixture 58 1, 2, 5, 8 4 3, 4 404
Fixture 59 2, 4, 5, 8 4 3, 4 411
Fixture 60 1, 6, 8 4 3, 4 418
Fixture 61 4, 6, 8 4 3, 4 425
Fixture 62 1, 2, 3, 4, 6, 8 4 3, 4 432
Fixture 63 2, 3, 5, 6, 8 4 3, 4 439
Fixture 64 1, 3, 4, 5, 6, 8 4 3, 4 446
Fixture 65 3, 7, 8 4 3, 4 453
Fixture 66 1, 2, 4, 7, 8 4 3, 4 460
Fixture 67 2, 5, 7, 8 4 3, 4 467
Fixture 68 1, 4, 5, 7, 8 4 3, 4 474
Fixture 69 6, 7, 8 4 3, 4 481
Fixture 70 1, 2, 3, 6, 7, 8 4 3, 4 488
Fixture 71 2, 3, 4, 6, 7, 8 4 3, 4 495
Fixture 72 1, 3, 5, 6, 7, 8 4 3, 4 502*
Table A-1. Starting channels in 7-channel DMX 512 protocol
Numerical
Order In
Link
Address
DIP Switches
ON
Personality DIP
Switches ON
Low High
Resolution Resolution
DMX
Starting
Channel
