High End trackspot - Page 64

A-6
Start Channels and Construct Parameters
Trackspot User Manual
4
Gobo
Wheel
open / gobo 1
forward gobo spin 7
forward gobo spin 6
forward gobo spin 5
forward gobo spin 4
forward gobo spin 3
forward gobo spin 2
forward gobo spin 1
reverse gobo spin 7
reverse gobo spin 6
reverse gobo spin 5
reverse gobo spin 4
reverse gobo spin 3
reverse gobo spin 2
reverse gobo spin 1
gobo 2
gobo 3
gobo 4
gobo 5
gobo 6
gobo 7
gobo 8
gobo 9
gobo 10
open / gobo 1
0
10
18
28
38
46
56
64
82
92
99
110
117
128
135
155
179
191
201
209
217
227
235
245
252
0
4
7
11
15
18
22
25
32
36
39
43
46
50
53
61
70
75
79
82
85
89
92
96
99
0
A
12
1C
26
2E
38
40
52
5C
63
6E
75
80
87
9B
B3
BF
C9
D1
D9
E3
EB
F5
FC
5 Shutter
closed
open
strobe 1
strobe 2
strobe 3
strobe 4
strobe 5
strobe 6
strobe 7
closed
open
0
26
51
77
102
128
153
179
204
230
242
0
10
20
30
40
50
60
70
80
90
95
0
1A
33
4D
66
80
99
B3
CC
E6
F2
6 Dimmer closed-open 0-255 0-100 00-ffh
7 MSpeed slowest-fastest 0-255 0-100 00-ffh
Table A-3. Construct parameters in DMX 512 high resolution mode
DMX
Channel
Function
High Resolution
Parameters
Decimal Percent Hex
