HIKVISION DS-K1T321 Series User Manual

Figure 7-4 ISUP Sengs
2.
Enable the ISUP funcon and set the ISUP server parameters.
ISUP Version
Set the ISUP version according to your actual needs.
Central Group
Enable central group and the data will be uploaded to the center group.
Main Channel
Support N1 or None.
ISUP
Enable ISUP
funcon and the data will be uploaded via ISUP protocol.
Address Type
Select an address type according to your actual needs.
IP
Set the ISUP server's IP address.
Port
Set the ISUP server's port No.
Note
Port No. Range: 1 to 65535.
Device ID
Set device serial no.
ISUP Key
DS-K1T321 Series Face Recognion Terminal User Manual
27
