2.1 Lamp Malfunction
Chapter 2: Troubleshooting Procedures
Page 2 - 6 Prima™ Procedural Light Service Manual (man247ra)
DRAFT 6/4/99
7. Inspect the wires for damage. The wires are in proper working condition.
Yes No
↓→Replace the damaged wire. If this solves the problem, go to
“Final Actions” on page 2-4. Otherwise, go to step 8.
8. Inspect the transformer for proper voltage output. The voltage output of the
transformer is 13 volts.
Yes No
↓→Replace the transformer. See “Transformer” on page 4-22. If this
solves the problem, go to “Final Actions” on page 2-4.
Otherwise, go to step 9.
9. Activate the power switch to the “ON” and “OFF” position. The power
switch is in proper working condition.
Yes No
↓→Replace the lamp head/yoke assembly. See “Lamp Head/Yoke
Assembly” on page 4-13. If this solves the problem, go to “Final
Actions” on page 2-4. Otherwise, call Hill-Rom Technical
Support at (800) 445-3720.
10. Go to “Final Actions” on page 2-4.
