4.8 Power Cord
Chapter 4: Removal, Replacement, and Adjustment Procedures
Prima™ Procedural Light Service Manual (man247ra) Page 4 - 21
DRAFT 6/4/99
4
4. Using a small phillips head screwdriver, remove the screws (D) and the
wire clamp (E).
5. Using a small screwdriver, loosen the screws (F) on the connector (G).
6. Note the position of the brown wire (H) and the blue wire (J) before
removing the power cord (K).
7. Remove the brown wire (H) and the blue wire (J) from the connector (G).
8. Remove the power cord (K) from the transformer housing (B).
Replacement
1. Install the brown wire (H) and the blue wire (J) to the connector (G), as
noted in the removal procedure.
2. Using a small screwdriver, tighten the screws (F) on the connector (G).
3. Properly position the power cord (K) to exit the transformer housing (B).
4. Install the wire clamp (E) and screws (D), using a small phillips head
screwdriver.
SHOCK HAZARD:
Do not pinch the wires during installation. Pinched wires can cause an
electrical shock hazard, resulting in personal injury or equipment
damage.
5. Taking care not to pinch wires, install both halves of the transformer
housing (B) to the upright pole (C).
6. Using a small screwdriver, install the screws (A) to the transformer housing
(B).
WARNING:
After completing a repair of the Prima™ Procedural Light, make sure
the unit is in proper operating condition. Failure to do so could result in
personal injury or equipment damage.
7. After completing a repair of the Prima™ Procedural Light, perform the
preventive maintenance checks to make sure the unit is in proper operating
condition. See “Preventive Maintenance Schedule” on page 6-7.
