Hill-Rom Prima Procedural Light - Replacement

4.9 Transformer
Chapter 4: Removal, Replacement, and Adjustment Procedures
Prima™ Procedural Light Service Manual (man247ra) Page 4 - 23
DRAFT 6/4/99
4
4. Remove the terminal block covers (H).
5. Using a small screwdriver, loosen the screws (D) on the connectors (E).
6. Note the positioning of the brown and the blue wires before removing them
from the connectors (E).
7. Remove the wires (F) from the connectors (E).
8. Remove the transformer (G) from the transformer housing (B).
NOTE:
The transformer is held in place with double sided tape.
Replacement
1. Install the transformer (G) into the transformer housing (B).
2. Install the wires (F) to the connectors (E), as noted in the removal
procedure.
3. Using a small screwdriver, tighten the screws (D) on the connectors (E).
4. Install the terminal block cover (H).
SHOCK HAZARD:
Do not pinch the wires during installation. Pinched wires can cause an
electrical shock hazard, resulting in personal injury or equipment
damage.
5. Taking care not to pinch wires, install both halves of the transformer
housing (B) to the upright pole (C).
6. Using a T10 Torx®
1
wrench, install the screws (A) to the transformer
housing (B).
1. Torx® is a registered trademark of Textron, Inc.
