Page #55 background imageLoading...
Page #55 background image
4.7 Upright Pole
Chapter 4: Removal, Replacement, and Adjustment Procedures
Prima™ Procedural Light Service Manual (man247ra) Page 4 - 19
DRAFT 6/4/99
4
5. Remove the wing bolt (C) and lockwasher (D).
6. Remove the upright pole (E) from the base (F).
Replacement
1. Install the upright pole (E) into the base (F).
2. Install the wing bolt (C) and lockwasher (D).
3. Install the upright locks (B) and the screws (A), using a small phillips head
screwdriver.
4. Replace the rotating arm. See “Rotating Arm” on page 4-15.
5. Replace the lamp head/yoke assembly. See “Lamp Head/Yoke Assembly”
on page 4-13.
