Hill-Rom Prima Procedural Light User Manual

Lamp Head/Yoke Assembly
Chapter 5: Parts List
Prima™ Procedural Light Service Manual (man247ra) Page 5 - 11
DRAFT 6/4/99
5
Table 5-2. Lamp Head/Yoke Assembly
Item Number Part Number Quantity Description
1 64927 (7925) 1 Lamp head/yoke assembly
2 64954 (7925) 1 Yoke subassembly
3 64955 (7925) 1 Housing subassembly
4 64956 (7925) 1 Pivot, lower yoke, small
5 64985 (7925) 1 Washer
6 64957 (7925) 1 Washer, cap retention, small
7 64958 (7925) 1 Washer, belleville, spring
8 64959 (7925) 1 Washer
9 64960 (7925) 1 Nut, hex
10
11 64962 (7925) 2 Insulation, #8 fiberglass sleeve
12 64963 (7925) 2 Connector, crimp, 1/4" closed loop
13 64964 (7925) 1 Main support plate subassembly
14 64965 (7925) 5 Lockwasher
15 64966 (7925) 3 Nut, 1/4"—32 hex
16 64967 (7925) 3 Banana jack
17 64968 (7925) 1 Handle mount
18 64969 (7925) 2 Lockwasher
19 64970 (7925) 2 Screw
20 64971 (7925) 2 Spacer
21 64972 (7925) 3 Clip subassembly
22 64973 (7925) 1 Reflector, dichroic glass
23 64974 (7925) 1 Clamping ring
24 64975 (7925) 1 Lens subassembly
25 64976 (7925) 3 Screw, pan head
26 64977 (7925) 3 Lockwasher, external tooth
27 64978 (7925) 1 Rear cover subassembly
28 64979 (7925) 1 Bezel
29 64980 (7925) 1 Cap, yoke, small
30 64981 (7925) 1 Lamp holder subassembly
31 69141 (7925) 1 Lamp, quartz halogen
