3 Product Description F3 AIO 8/4 01
Page 20 of 54 HI 800 161 E Rev. 1.01
3.5 Assembly
This chapter describes the layout and function of the remote I/Os, and their communication
via safeethernet.
AIO
8/4 01
Figure 4: Front View
8 Analog Inputs
Safety-Related Processor System
Switch
Watchdog
4 Analog Outputs
Figure 5: Block Diagram
