Page #27 background imageLoading...
Page #27 background image
F3 AIO 8/4 01 3 Product Description
HI 800 161 E Rev. 1.01 Page 27 of 54
Supply outputs
Number of supply outputs 8
Nominal voltages 8.2 VDC / 26 VDC, switchable
Tolerance
± 5 %
Safely monitored limits
Range 8.2 V
Range 26 V
7.6 V...8.8 V, (tolerance range: 7.3...9.1 V)
24.3 V...27.7 V, (tolerance range: 24.0...28.0 V)
Current limiting > 200 mA, the output is switched off
Table 18: Specifications for the Transmitter Supply
Analog Outputs
Number of outputs
4 non-galvanically isolated,
non-safety-related,
common safe shutdown
Nominal value 4...20 mA
Operating value 0...21 mA
Digital resolution 12-bit
Load impendance
max. 600 Ω
Measurement accuracy at
25 °C, max.
±0.1 % of final value
Measurement accuracy on
full temperature range, max.
±0.5 % of final value
Temperature coefficient,
max.
±0.011 %/K of final value
Safety-related accuracy,
max
±1 % of final value
Table 19: Specifications for the Pulsed Outputs
3.6.1 Product Data F3 AIO 8/4 011 (-20 °C)
The HIMatrix F3 AIO 8/4 011 (-20 °C) model variant is intended for use at the extended
temperature range of -20…+60 °C. The electronic components are coated with a protective
lacquer.
General
Operating
temperature
-20 °C...+60 °C
Weight approx. 0.95 kg
Table 20: Product Data of F3 AIO 8/4 011 (-20 °C)
3.6.2 Product Data F3 AIO 8/4 012 (subsea / -20°C)
The HIMatrix F3 AIO 8/4 012 (subsea / -20°C) model variant is intended for subsea-use
according to ISO 13628 Part 6: Subsea production control systems. The electronic
components are coated with a protective lacquer. The enclosure of the remote I/O is made
of V2A stainless steel; the remote I/O is intended for mounting on a mounting plate. The
enclosure is equipped with a massive aluminum plate, see
Figure 7. Figure 8 specifies the
centre hole distances.
