3 Product Description F3 AIO 8/4 01
Page 26 of 54 HI 800 161 E Rev. 1.01
3.6 Product Data
General
Response time 20 ms
Ethernet interfaces 2 x RJ-45, 10/100BaseT (with 100 Mbit/s) with integrated switch
Operating voltage 24 VDC, -15 %...+20 %, w
ss
15 %,
from a power supply unit with safe insulation in accordance with
IEC 61131-2.
Current input
max. 0.8 A (with maximum load)
Idle: approx. 0.4 A at 24 V
Fuse (external) 10 A time-lag (T)
back-up battery None
Operating
temperature
0 °C...+60 °C
Storage temperature -40 °C...+85 °C
Type of protection IP20
Max. dimensions
(without plug)
Width: 207 mm (with enclosure screws)
Height: 114 mm (with fixing bolt)
Depth: 97 mm (with earthing rail)
Weight 0.95 kg
Table 16: Product Data
Analog inputs
Number of inputs 8 (non-galvanically isolated)
Nominal range
0...+10 VDC,
0/4...+20 mA with 500 Ω shunt
Operating range
-0.1...+11.5 VDC,
-0.4...+23 mA with 500 Ω shunt
Input resistance
> 2 MΩ
Source resistance input
of the input signal
≤ 500 Ω
Digital resolution 12-bit
Measurement accuracy at
25 °C, max.
±0.1 % of final value
Measurement accuracy on
full temperature range, max.
±0.5 % of final value
Temperature coefficient,
max.
±0.011 %/K of final value
Safety-related accuracy,
max
±2 % of final value
Measured value refresh once per cycle of the controller
Sampling time approx. 45 µs
Table 17: Specifications for the Analog inputs
