HIMA HIMatrix F3 AIO 8/4 01 User Manual

4 Start-Up F3 AIO 8/4 01
Page 42 of 54 HI 800 161 E Rev. 1.01
NOTE
Overload, failure due to improperly set voltage (8.2 V / 26 V)!
Failure to comply with these instructions can damage the electronic components.
Prior to start-up, set the Transmitter Supply[01] system parameter to 1 (8.2 V). If the
shunt adapter has been overloaded, it must be replaced.
4.5.1.1 Limits to Configure in the User Program
The following values concerning a final value of 2000 digits, must be configured in the user
program. The line resistance has already been taken into account with the limits.
Standard values for the digital inputs
NAMUR proximity switches in
accordance with EN 60947-5-6
Verify the values of the proximity switches actually in
use.
Switch-on threshold Low -> High
1.75 mA [175 digits]
Switch-off threshold High -> Low
1.55 mA [155 digits]
Open-circuit (LB)
≤ 0.200 mA [20 digits]
Short-circuit (LS)
≥ 10.86 mA [1086 digits]
SN / S1N proximity switches
from P+F
Verify the values of the proximity switches actually in
use.
Switch-on threshold Low -> High
2.45 mA [245 digits]
Switch-off threshold High -> Low
2.25 mA [225 digits]
Open-circuit
≤ 0.200 mA [20 digits]
Short-circuit
≥ 5.63 mA [563 digits]
Table 32: Standard Values for the Digital Inputs
