HIMA HIMatrix F3 AIO 8/4 01 User Manual

3 Product Description F3 AIO 8/4 01
Page 28 of 54 HI 800 161 E Rev. 1.01
General
Enclosure material V2A stainless steel
Operating
temperature
-20 °C...+60 °C
ISO 13628-6: 2006 Shock and vibration tests according to Level Q1 and Q2.
Random vibration test, ESS (environmental stress screening)
Max. dimensions
(without connectors
and aluminum plate)
Width: 207 mm (with enclosure screws)
Height: 114 mm (with fixing bolt)
Depth: 97 mm (with earthing rail)
Dimensions:
Aluminum plate
(W x H x D)
(200 x 160 x 6) mm
Weight approx. 1.4 kg
Table 21: Product Data of F3 AIO 8/4 012 (subsea / -20°C)
Figure 7: HIMatrix F3 AIO 8/4 01 012 (Subsea / -20°C) with Aluminum Plate
