F3 AIO 8/4 01 3 Product Description
HI 800 161 E Rev. 1.01 Page 29 of 54
Figure 8: Aluminum Plate with Dimensions
3.7 Certified HIMatrix F3 AIO 8/4 01
HIMatrix F3 AIO 8/4 01
CE EMC, ATEX Zone 2
TÜV IEC 61508 1-7:2000 up to SIL 3
IEC 61511:2004
EN 954-1:1996 up to Cat. 4
TÜV ATEX 94/9/EG
EN 1127-1
EN 61508
UL Underwriters
Laboratories Inc.
ANSI/UL 508, NFPA 70 – Industrial Control Equipment
CSA C22.2 No.142
UL 1998 Software Programmable Components
NFPA 79 Electrical Standard for Industrial Machinery
IEC 61508
FM Approvals Class I, DIV 2, Groups A, B, C and D
Class 3600, 1998
Class 3611, 1999
Class 3810, 1989
Including Supplement #1, 1995
CSA C22.2 No 142
CSA C22.2 No 213
Table 22: Certified HIMatrix F3 AIO 8/4 01
